Frequency
9380 ~ 9440 MHz (Fixed)
Output power (Peak)
25 kW
Duty cycle / Pulse duration
0.001 / 1.2 μsec
Other features
RoHS compliant
| Items | Parameters |
| Anode voltage (Peak) | 8 kV |
|---|---|
| Anode current (Peak) | 8 A |
| Heater voltage | 6.3 V |
| Heater current | 0.52 A |
| RF output interface |
Waveguide : WR90 RF flange : UG-135/U Equivalent |
| Power supply interface | Lead wire |
| Cooling | Air / Forced air |
| Weight | 0.7 kg |
