Frequency
9380 ~ 9440 MHz (Fixed)
Output power (Peak)
25 kW
Duty cycle / Pulse duration
0.001 / 1.00 μsec
Other features
RoHS compliant

Items	Parameters
Anode voltage (Peak)	8 kV
Anode current (Peak)	8 A
Heater voltage	6.3 V (@ Preheat)
Heater current	0.52 A
RF output interface	Waveguide : WR90 RF flange : UG-135/U Equivalent
Power supply interface	Socket type
Cooling	Air / Forced air
Weight	1.5 kg
