| Type |
Frequency (MHz) |
Peak Power Output (kW typ.) |
Pulse duration (μsec) |
Duty Cycle |
Peak Anode Voltage (kV) |
Peak Anode Current (A) |
Heater Voltage (V) |
Heater Current (A) |
Class |
Weight (kg) |
| M1913A | 5500 ~ 5700 | 300 | 2.4 | 0.001 | 26 | 30 | 5 | 19 | MWAPL | 26 |
|---|---|---|---|---|---|---|---|---|---|---|
| M1913S | 5450 ~ 5820 | 250 | 2 | 0.001 | 25 | 24 | 9.5 | 11 | MWAPL | 24 |
| M1941 | 5250 ~ 5400 | 300 | 2.4 | 0.001 | 26 | 30 | 5 | 19 | MWAPL | 26 |
Class：［Tuning］F : Fixed / M : Mechanical
［Output］C : Coaxial / W : Waveguide
［Cooling］A : Forced Air / L : Liquid
［Magnet］P : Permanent / S : Separate
［Input］S : Socket / L : Lead
